Name: Low Temperature Air Source Heat Exchanger Heat Pump Coefficient Of Performance 3.81
Brand: Power World
SKU: MG-050KFLW
Rating: 5 (114 reviews)

Home Products Air Compressor Heat Exchanger

Low Temperature Air Source Heat Exchanger Heat Pump Coefficient Of Performance 3.81

Product Details:

Place of Origin:	China
Brand Name:	Power World
Certification:	CE,IEC,EC,ETL,CETL,C-TICK,WATER MARK,STANDARD MARK,SABS,SANS,SAA
Model Number:	MG-050KFLW

Payment & Shipping Terms:

Minimum Order Quantity:	1 PCS
Price:	negotiation
Packaging Details:	Plywood packing
Delivery Time:	15-20 working days after received payment
Payment Terms:	Western Union, L/C, D/A, T/T
Supply Ability:	9,000pcs per month

Contact Now

Detailed Product Description

Application:	Hot Water,heating And Cooling	Color:	White,gold,Grey
Size:	11104901260	Packaging:	Plywood CTN
Refrigerant:	R407C	Power Supply:	380V/ 50HZ
High Light:	low temperature air source heat pump , heat exchanger Heat Pump

20.6 KW Low Temperature Air Source Heat Pump with high COP and low noise

Specifications:

Product model		MG-050KFLW
Body size(WDH) MM		11104901260
Compressor		Copeland
Refrigerant		R407C
Power supply		380V/50Hz
Condenser		Efficient tank
Condenser		Efficient tank
Thermostatic expansion valve		Danfoss
AC contactor		(220V-18A)
Controller		Dual system
Low-voltage switch		0.05/0.15MPa
High-voltage switch		3.0/3.6MPa
Power line connect with unit		34mm²+22.5mm²
20℃	Heating capacity (kW)	20.6
	Input power (kW)	5.4
	Rated current (A)	9
	COP	3.81
	Production capacity (L/H)	443
-10℃	Heating capacity (kW)	12.6
	Input power (kW)	5.1
	COP	2.47
	Production capacity (L/H)	271
-20℃	Heating capacity (kW)	10.3
	Input power (kW)	5.05
	COP	2.04
	Production capacity (L/H)	221
-25℃	Heating capacity (kW)	9.5
	Input power (kW)	5.05
	COP	1.88
	Production capacity (L/H)	204
Rated outlet hot water temperature (℃)		55
Highest outlet hot water temperature(℃)		60
IP Grade (Level of protection)		IPX4
Anti-electric shock Rate		I
Noise (dB(A))		≤58
Net weight/Gross weight((kg)		145/155
Diameter of pipe (mm)		DN25

Description

1. Environmental friendly and safe

Electric parts and water system is completely cut off, ensuring security water use, no pollution to the atmosphere and free of greenhouse effect and it is the safest water heater

2. Wide climatic zone adaptability

Our heat pumps with special designing possess better climatic adaptability, can work from -25℃ to 43℃.

3. Energy-saving

Heat pump water heater is a high efficient transferring heating equipment which is driven by electricity. The operating cost is only 1/4 of electric water heater, 1/3 of gas water heater.

4. Automatic intelligent control system

Adopting intelligent computerized automatic control system, no manual cost, easy to operate, convenient, make heat pump work safely and reliably.

Control panel with modularized unit design can control more flexible heat pumps packs, with user-friendly operating system interface, easy to operate..

5. Advanced testing methods

Adopting world-class Enthalpy potential laboratory to test heat pumps, except basic testing items, we also test heat pump in the ambient of temperature of -30℃ to test our heat pump performance.

6. Widely used

Heat pump is applied to hot water for household and commercial use like families, schools, hospitals, shower center, swimming pools, etc. and industrial use like electroplating, drying, etc.

Application:

Business Organizations	supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
Financial Organizations	Banks, negotiable securities, funds, insurance companies, pawnshops; Non-profit Organizations: Telecommunications, post offices, hospital, schools;
Public Places	subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
Entertainments	Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course

Competitive Advantage:

1. EVI technology:

Adopting the most advanced low temp Enhanced Vapors Injection compressor technology which can help heat pump work steadily even at temperature of -25℃.

2. Wide range of temperature:

EVI heat pump can work from -25℃.to 43℃. Widely used in different environment.

3. Higher heating capacity:

Using enlarging evaporator extracting more heat energy from air will increase COP.

4. Automatic start-up anti-freezing protection

When the ambient is below zero degree, the unit is in standby mode more than 30 minutes, Automatic anti-freezing device will be started up so that the unit will be protecting in lower temperature.
