Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar

Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar

  • Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar
  • Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar
  • Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar
  • Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar
Vacuum Brazed Aluminum Air Compressor Heat Exchanger Radiator , 2-40 bar
Product Details:
Place of Origin: China
Brand Name: Jinxi
Certification: ISO9001:2008
Model Number: Air Compressor-2603
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Wooden/paper box
Delivery Time: 10-15 working days
Payment Terms: T/T ,Western union
Supply Ability: 130Tons/month
Contact Now
Detailed Product Description
High Light:

Fully welded heat exchanger

,

air compressor cooler

Vacuum Brazed Aluminum Plate And Fin Radiator For Compressor​



Quick Detail:



Name Compressor Radiator Brand Name Jinxi
Color Silver / black Feature Resistant to vibration,Good cooling efficiency
Technique Brazing / Welding Certificate ISO9001:2008





1. Specifications

  • Working pressure:2-40 bar
  • Working temp:-10-220 Deg C
  • Applications: Screw air Compressor, slidingwane compressor , scroll compressor
  • Type: Plate and fin
  • Highly flexible complete,ready-to-use cooling packages
  • Compact and robust design
  • Largest and most comprehensive series of oil-air radiators.



2. Description:

  1. Air radiator
  2. Fan mounting
  3. Air guide
  4. Electric fan 24Volt
  5. Screw Hex Hd M6 x 20 Zinc plated
FIN SPEC.
Fins Pitch(mm/FPI) G(mm) H(mm)
Louvered Fin 2.5~5mm/10~20FPI 0.1~0.17 6.5~18
Wavy Fin 2.5~8mm/6~20FPI 0.1~0.35 2.5~12
Flattop Fin 2.1~10mm/5~20FPI 0.1~0.2 2.5~12
Offset Fin1 4.5~8mm/6~16FPI 0.15~0.5 1~5
Offset Fin2 4~8mm/6~13FPI 0.12~0.2 5~18





Place of Origin: China
Brand Name: Jinxi
Certification: ISO9001:2008
Model Number: Air Compressor-2603





Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Wooden/paper box
Delivery Time: 10-15 working days
Delivery Terms: FOB shanghai
Payment Terms: T/T ,Western union
Supply Ability: 130Tons/month





Welcome to take a reference:



1) The Most Efficient Service, Best Quality and Excellent Reputation



2) Design term:We have professional design team.



3) A manufacturer deserved to cooperate.



4) Company feature : We treasure our every customer what is the scale of their company.



5) Excellent quality with production instruction.



6) OEM&ODM service provided
