| Place of Origin: | China |
| Brand Name: | ADV-Ti |
| Certification: | ISO UKAS SGS |
| Model Number: | GR1 GR2 GR7 GR12 |
| Minimum Order Quantity: | 10kg |
|---|---|
| Price: | Negotiable |
| Packaging Details: | wooden box |
| Delivery Time: | 15days~30days |
| Payment Terms: | L/C,T/T,Western Union |
| Supply Ability: | 5 Tons per Month |
| High Light: | titanium welded pipe,alloy metals and tubes |
||
|---|---|---|---|
1. Standards: ASTM B/ASME SB 338, 862
2. Gr.1, Gr.2, Gr.7, Gr.12
3. OD: 5-160mm; WT: 0.5-10mm; Length: less than 15 meters
Features:
1) Standards: ASTM B/ASME SB 338, 862
2) Gr.1, Gr.2, Gr.7, Gr.12
3) Seamless and welded pipe
4) OD: 5-160mm; WT: 0.5-10mm; Length: less than 15 meters
5)Eddy Current Testing,Ultrasonic
6) We are checked by A&V,B&V,SGS
7) Used area:Heat exchangers and condensers
All kinds of corrosive fluid transmission pipeline system
Titanium bicycle tubes, automobile exhaust pipe
Offshore aquaculture
8) OEM and customers’ designs are acceptable
9) Final product test: Ultrasonic test, Eddy current test, Hydraulic test, Bend test, Flaring test and so on.
Specifications:
|
Grade |
Condition |
Manufacturing Method |
OD |
Wall Thickness |
Long |
Standard |
|
Gr1 Gr2
|
Annealed |
Cold rolling Seamless |
10-15MM |
0.5-4.5 MM |
500-4000MM |
ASTM B337 ASTM B338 |
|
15-20MM |
0.6-2.5 MM |
500-9000MM |
||||
|
20-30MM |
0.6-2.5 MM |
|||||
|
30-40MM |
1.0-2.5 MM |
|||||
|
40-50MM |
1.5-3.0 MM |
|||||
|
50-60MM |
1.5-3.5 MM |
|||||
|
60-80MM |
2.0-4.5 MM |
|||||
|
Welded |
16MM |
0.5-1.0 MM |
500-15000MM |
|||
|
19MM |
0.5-1.25MM |
|||||
|
25 27MM |
0.5-1.5 MM |
500-6000MM |
||||
|
31 32 33MM |
0.8-2.0 MM |
|||||
|
38MM |
1.5-2.5 MM |
500-4000MM |
||||
|
50MM |
2.0-2.5 MM |
|||||
|
63MM |
2.0-2.5 MM |
|||||
|
Welded ------- Rolling |
6-10MM |
0.5-1.25 MM |
500-8000MM |
|||
|
10-15MM |
0.5-1.5 MM |
|||||
|
15-20MM |
0.5-2.0MM |
500-5000MM |
||||
|
20-25MM |
0.5-2.0 MM |
|||||
|
25-30MM |
0.5-2.0MM |
|
Titanium welded pipe for heat exchanger equipments Titanium welded pipe for chemical and Oil industry |
ASTM B338, ASTM B862 |
Gr1 GR2 GR7 GR12 |
OD (10.3~914) = (1/8~36)Inch WT (0.5~30.96) = (0.049~1.219) Inch Length |
|
Titanium seamless tube (heat exchanger ) |
ASTM B338, ASTM B337, ASTM B861 |
GR1 GR2 GR3 GR5 GR6 GR7 GR9 GR12 GR16 GR17 etc. |
OD (1.5~420) × WT (0.3~16 ) × Length 18000 mm |
Shipping:
Productive Technology —— Seamless Titanium Pipe
