1000ML Horizontal packaging machine for peanuts beans , milk pouch

Product Details:

Place of Origin:	China
Brand Name:	Strpack
Certification:	CE
Model Number:	STH

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	Negotiation
Packaging Details:	Export Standard Wooden Case
Delivery Time:	25days
Payment Terms:	T/T
Supply Ability:	15Set/Month

Contact Now

Detailed Product Description

Bag Width:	90-180 Mm	Bag Height:	110-260 Mm
Filling Volume:	1000ml(maximum)	Environment Temperature:	-10℃—＋55℃
Relative Humidity:	< 85%( Non-condensing)	Voltage:	AC380V
High Light:	beverage packaging machine , industrial packaging machinery

STH-180D Automatic horizontal doypack packing machine

Quick Detail:

STH-180D Automatic horizontal doypack packing machineIt can be used to pack granules such as peanuts, beans, seeds, candies, and also can pack liquid, thick liquid and powder, etc. with corresponding measuring and filling device. The filling capacity can up to 1000ml.
The machine can automatically finish bag forming, filling, easy tear notch making, print date, finished bag discharged. Reclosable zipper, spout, nitrogen flushing, unique bag shape, hole and round corner punching are optional.

1. Versatility strong, one machine can be realized powder, liquid, granules, paste different types of

packaging materials.

2. Automatic servo-correcting device can effectively solve the bag wrong side of the issue to ensure the overall stability of equipment, improve packaging speed.

3. Linear servo pull bag system that automatically adjust bag width size, improve equipment stability.

4. Product packaging system: using heat sealing packaging materials (polyethylene, multilayer composite coating), the automatic bagging completed. Measures such as packaging filling and sealing process fully automated production facilities. Trilateral closure pocket or bag is a four-sided flat closure. Use different forms of filling machine, and packaging different products.

5. Control System: PLC programmable computer controller Schneider-electric inverter and so on, high integration, the ability to control and reliable operation .Touch screen technology enabled applications to operate machines more reliable and convenient .Photoelectric sensor, encoder, the switches are close to the import of advanced sensors. Machinery and electronics integration has been a perfect performance.

Description:

Item	Main features
Main machine frequency control of speed	Import AC motor & frequency control speed, stable operation, lower speed with bigger torque lead to a nice function even with a heavier load
Bag making system	Bag making system is separate from sealing. They are working under the control of PLC. It is suitable for different products & bag sizes
Products sealing system	It adopts hot sealing packaging material such as PE, complex film , etc. Automatic bag making, dosing, filling and packaging. Bag type is stand-up pouch. It can adopts various filling machines, then suitable for different products
Servo bag guiding device	It adopts PLC position module realizes the accurate positioning. Stable film guiding speed with big torque, guarantee lower error rate & nice appearance
Integrated control system	It adopts PLC, frequency control device which with a powerful control & stable operation. Touch screen lead to an easy operation. Import photoelectric sensor, encoder, proximity switch, etc presents a nice mechanotronics.

Specifications:

Item		parameter
packaging parameter	Bag width	90-180 mm
	Bag height	110-260 mm
	Filling volume	1000ml(maximum)
Equipment dimensions	Width	1100mm
	Length	6000mm
	Height	1500mm
	Weight	About 2000Kg
Working conditions	Environment temperature	-10℃—＋55℃
	Relative humidity	< 85%( Non-condensing)
	Voltage	AC380V
	Power frequency	50Hz
	Power	8Kw
	Working air pressure	0.5MPa
	Air consumption	300NL/min
