Name: Seamless Copper Nickel Tube 2015Hot Sale C70600, C71500 70/30
Brand: Shenzhen SAE Automotive Equipment Co.,Ltd
SKU: Seamless copper nickel tube CUNI pipe C70600, C71500 2015 Hot sale 70/30 Copper nickel tube /0/10 Copper nickel tube
Availability: InStock

Home Products Finned Tube Heat Exchanger

Seamless Copper Nickel Tube 2015Hot Sale C70600, C71500 70/30

Product Details:

Place of Origin:	China/Japan/Germany
Brand Name:	TOBO/TPCO/TISCO/VALIN/METAL
Certification:	ISO/PED/TUV/SGS/LR/BV
Model Number:	Seamless copper nickel tube CUNI pipe C70600, C71500 2015 Hot sale 70/30 Copper nickel tube /0/10 Copper nickel tube

Payment & Shipping Terms:

Minimum Order Quantity:	1M
Price:	USD
Packaging Details:	PLY-WOODCASE
Delivery Time:	5-65workdays
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Supply Ability:	30000TON/YEAR

Contact Now

Detailed Product Description

Standard:	C70600, C71500 ASTM B111 ASTM B466, B359	Length:	Single Random, Double Random & Cut Length
End:	These Pipes Have Plain End, Beveled End, Threaded And Features Like Hot Dipped Galvanizing, Epoxy & Fbe Coating And Electro Polish	Grade:	C70600, C71500 ASTM B111 ASTM B466, B359
Color:	Black Or Red	Types:	Seamless
ASTM:	C70600, C71500 ASTM B111 ASTM B466, B359	Form:	Round, Square, Rectangular, Hydraulic Etc
Highlight:	copper nickel tubing

Seamless copper nickel tube CUNI pipe C70600, C71500 2015 Hot sale 70/30 Copper nickel tube /0/10 Copper nickel tube

Copper nickel tube, ASTMB111,C70600,manily be used in the heat exchanger,ship building ,power station and so on;

1.   Standard Applied: ASTM B111 (ASTM B466, ASTM B359, ASTM 395), JIS H3300, BS EN 12451, EN 12449, GB/T8890 etc.

2.   Quality : bright ,clean and smmoth in the surface; No burr in the end ; Eddy Current test is ok ;

3. Specification :   O.D 2mm to O.D 40mm;     Length can up to 12m;

4. The brass tubes are widely used in Steam Turbines, Seawater Desalination Equipments, Petrochemical Plants, Power Plants, Coolers, Boiler, Water Evaporators, Oil Refineries, and Shipbuilding.

5. Material Designation Applied: C71500, C70600, C71640, C68700, C44300, C26130 etc.

6. Material Brand:

Grade	USA	U.K	Germany	Japan
China BG	ASTM	BS	DIN	JIS H
BFe10-1-1	C70600	CN102	CuNi10Fe1Mn	C7060
BFe30-1-1	C71500	CN107	CuNi30Mn1Fe	C7150
HAL77-2	C68700	CZ110	CuZn22Al	C6870
HSn70-1	C44300	CZ111	CuZn28Sn1	C4430
H68A	C26130	CZ126	-----	-----

Series 1 Copper Nickel Tubes	Standard Grade					Dimensions (mm)
Material	EN12451	ASTM B111	ASME SB111	JIS H3300	BS2871 Part3	OD Range	WT Range
90/10 Copper Nickel Alloy C70600	CuNi10Fe1Mn CW352H	C70600	C70600	C7060	CN102	4~50	0.2~5
70/30 Copper Nickel Alloy C71500	CuNi30Mn1Fe CW354H	C71500	C71500	C7150	CN107	4~50	0.2~5
Copper Nickel Iron Manganese Alloy C71640	CuNi30Fe2Mn2 CW353H	C71640	C71640	C7164	CN108	4~50	0.2~5

Series 2 Brass Tube	Standard Grade					Dimensions (mm)
Material	EN12451	ASTM B111	ASME SB111	JIS H3300	BS2871 Part3	OD Range	WT Range
Admiralty Brass Alloy C44300	CuZn28Sn1As CW706R	C44300	C44300	C4430	CZ111	4~50	0.2~5
Aluminium Brass Alloy C68700	CuZn20Al2As cw702R	C68700	C68700	C6870	CZ110	4~50	0.2~5

Series 2 Brass Tube	Standard Grade		Dimensions (mm)
Material	ASTM B135	JIS H3300	OD Range	WT Range
65/35 Copper Zinc Alloy C27000	C27000	C2700	4~50	0.2~5
63/37 Copper Zinc Alloy C27200	C27200	C2720	4~50	0.2~5

Series 3 Copper C12200	Standard Grade					Dimensions (mm)
Material	EN12451	ASTM B111	ASME SB111	JIS H3300	BS2871 Part3	OD Range	WT Range
Copper C12200	Cu-DHP	C12200	C12200	C1220	C106	4~50	0.2~5

Series 4 Nickel and Nickel Alloys Tubes	UNS N02200, N04400, N06600, N08800, Size range: OD 6.0~100mm, WT 0.5~8.0mm, up to 15 meters.

Series 5 High Effecient Tubes	Low fin tubes, corrugated tubes.
Remarks:	Dimensions of our normal product range, we are always trying to improve our range so please contact us if you are looking for other dimension.

Eddy current test

Direct-reading spectrometer

Ultrasonic detector

hydraulic test equipment

Chemistry laboratory

Universal testing machine

Hardness tester

Metallography microscope imported

Micro-analysis

Chemical analysis

Always seeking for perfection is our survival base. Modern enterprise pursues"Human-centered concept". We start with improving the quality of staff, and try to let us exert potential ability, so as to reach quality awareness, ensure first class quality. Perfection, is the persistent to details, perfection, is the challenge to technology, perfection, is the understanding to the foreword, perfection, is the nitpick to quality, perfection, is the fanaticism to highest level.

Wire cutting machine

Arldirect-reading spectrometer

Impact tester equipment
