Safety Plastic Auxiliary Equipment XC - W Air Cooled Water Chiller , CE

Safety Plastic Auxiliary Equipment XC - W Air Cooled Water Chiller , CE

  • Safety Plastic Auxiliary Equipment XC - W Air Cooled Water Chiller , CE
  • Safety Plastic Auxiliary Equipment XC - W Air Cooled Water Chiller , CE
Safety Plastic Auxiliary Equipment XC - W Air Cooled Water Chiller , CE
Product Details:
Place of Origin: Zhejiang China
Brand Name: HAICHEN
Certification: ISO9001:2000, CE
Model Number: XC-W SERIES
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Packaging Details: Wooden Carton
Delivery Time: 20Days
Payment Terms: L/C, T/T
Contact Now
Detailed Product Description
Application:: Modern Industry Feature:: High Efficiency
Product Name:: Water Chiller Model:: XC-W Series
High Light:

Air Cooled Water Chiller

Water Cooling Type Water Chiller, Plastic Auxiliary Equipment for Industrial



Additional equipment for option: 1 starter of timer switch  2 large type of water filter 3 protection switch for prove the electric leakage 4 cooling tower and pump.





Quick Detail:


The XC-W series of water-cooled water chillers use a single closed-loop design for pressurized refrigerant. All models are equipped with compressor and motor overload protection, phase shortage and reversal alarms, anti-freeze thermostat, pressure gauges, etc. They feature excellent performance and a long lifespan. The series of working flow is based on the basic principle of heat exchange. It is applicable to the industry that requires flow of precisely controlled chilled water, and considered as indispensable equipment for modern industry.





The water chiller is to provide cooling process to plastic moulds to improve molded products qual-0ity and cut down injection cycle time. Hence maximizes plastic molding machines productivity.

1. Installed with import brand compressors, highly efficient shell condenser and evaporator, excellent co-oling, quiet and low electricity consumption.

2. Microprocessor control, easy to operate;

3. Unique open reservoir tank made of stainless steel, easy cleaning and maintenance;

4 Pipeline well-arranged to save energy;




Main Features:



1. Compressor is usde"COPELAND" brand which made in USA. The inside safety protection can guarantee the long lasting of the chiller

2. The pump is used made in Taiwan and all parts of cooling system are imported from the USA, Mexico,Denmark and Japan

3. Equipped with shellpipe condenser and stainless steel cased evaporator, which are quite easy to be cleaned and maintained.

4. Complete with safety protection and error indication system, including pump over load protection, high pressure and low pressure protection and phase failure protection

5. Equipped wth figure intellectualized temperature controls, which can accurately measure and control water temperature within the range of 5°C-35°C

6. The industrial chiller is specially designed on purpose to be used in the plastic manufacturing industry.



Specifications XC-03WCI XC-05WCI XC-08WCI XC-10WCI XC-12WCI XC-15WCI
Cooling Capacity(kcal/h) 7580 13500 21150 28000 34400 41000
Compressor All-closed Vorticity
Compressor Power(kw) 2.5 4.4 7 9 10.2 13.4
Refrigerant R22(R407,R502 is alternative)
Chilled Water Pump Power(kw) 0.37 0.75 0.75 0.75 1.5 1.5
Max Flow Rate of chilled water(L/min) 90 115 115 123 217 217
Max.Pressure 22 28 28 22 25 25
Flow Water inlet and Outlet Pipe 1” 1” 1” 1.5” 1.5” 2”
Condensing Water Rate ≥36 ≥60 ≥100 ≥13 ≥200 ≥200
Chilled Water inlet and Outlet Pipe 1” 1” 1.5” 1.5” 1.5” 2”
Water Case Shape L(mm) 850 850 1000 1150 125 1500
W(mm) 560 560 750 800 850 900
H(mm) 870 1040 1100 1150 1050 1200
Water Tank Capa. 38 70 130 170 220 260
Wt. 160 185 260 300 320 450



Specifications XC-20WCI XC-25WCI XC-30WCI XC-40WCI XC-50WCI
Cooling Capacity(kcal/h) 50000 60000 77600 101780 121400
Compressor
Compressor Power(kw) 18 20.4 26.8 35 40
Refrigerant
Chilled Water Pump Power(kw) 2.2 2.2 4 7.5 7.5
Max Flow Rate of chilled water(L/min) 315 315 400 600 600
Max.Pressure 26 26 50 55 55
Flow Water inlet and Outlet Pipe 2” 2” 2.5” 3” 3”
Condensing Water Rate ≥240 ≥300 ≥300 ≥340 ≥400
Chilled Water inlet and Outlet Pipe 2” 2” 2” 2” 2”
Water Case Shape L(mm) 1700 1700 2100 2100 2300
W(mm) 950 1000 1100 1200 1400
H(mm) 1200 1300 1300 1500 1500
Water Tank Capa. 300 380 Non-Water Box(Dry-Type)
Wt. 630 700 750 860 1200
