R22 Commercial Ductless Split System Air Conditioner Heating And Cooling HVAC

Product Details:

Place of Origin:	China
Brand Name:	Head-Power
Certification:	CE, ISO
Model Number:	HAM10

Payment & Shipping Terms:

Minimum Order Quantity:	1set
Price:	negotiation
Packaging Details:	Wooden case/carton case
Delivery Time:	25~30days
Payment Terms:	TT, LC
Supply Ability:	3,000pcs per year

Contact Now

Detailed Product Description

Product Name:	Ductless Split Air Conditioner	Application:	Commercial Air Conditioning
Cooling Capacity:	26kw	Refrigerant:	R22 / R407C
Compressor:	Hitachi Scroll Compressor	Power Supply:	380V/3PH/50Hz
Material:	Painted Galvanized Steel Sheet	Color:	White Grey
Highlight:	split system air conditioner

Commercial Ductless Floor Standing Split Air Conditioner 400V / 3PH / 50Hz

Specifications:

Model			HAM10(H)
Cooling capcity		kW	26
Heating capacity		kW	27.5
Power supply			400V/3PH/50Hz
Refrigerant			R22
Air Volume		m3/h	4500
External static pressure		Pa	0
Compressor	Type		Hermetic Scroll
	Power	kW	7.9
	Quantity	pcs	2
Supply fan	Type		DIDW, centrifugal type
	Air volume	m3/h	4500
	Motor power	kW	2*0.55
	Drive method		Direct drive
Evaporator	Type		Copper tubes with aluminium fins
Throttle method			External balanced thermal expansion valve
Electric controller			LCD display screen, automatic microcomputer controller, failure alarm, balance operation time, Timer on/off,etc
Net weight		kg	160
Dimensions(LWH)		mm	1350x750x 1950
Matched condensing unit			SW10
Condener	Type		Copper tubes with hydrophilic aluminium fins
Condensing fan	Type		Axial type
Condensing fan	Power	kW	0.55
Dimensions(LWH)		mm	105010501150
Net weight		kg	240

Features:

1. Flexbile hermetic scroll compressor, high and steady working performance, Hitachi, Copeland, Sanyo, etc.
2. Independent refrigerant system: each compressor is equipped with an independent refrigerant circuit, easy for energy regulation, save energy and ensure running reliablity.
3. Supply fan: DIDW centrifugal fan, Chinese famous brand Deton, Yilida. Fan shaft use C-45 steel, well treated and anti-rust, easy for maintainance.
4. Microcomputer controller, simple interface, adjust temperature automatically, convenient for operation and easy for maintainance.
5. Galvanized steel sheet, outside powder coated, anti-corrosion and weather proof type condenser.
6. Floor standing ductlesstype, free blowing, long distance, beautiful apperance.

7. For standard model, compressors are installed in condensing unit.

8. Differenct kinds of refrigerant available: R22, R134a, R407C.

Applications:

Industry factories: Electronic factory,pharmaceutical factory, precision instrument factory,petrochemical

factory,tobacco factory, cooling for production process, etc

Public places: Airports, stations, exhibition halls, stadiums, museums, convention centers, apartments,

church,etc
