We are a professionalheat exchanger, condenser, evaporator and heat pump
manufacturer in China, which has more than 15 years experience in HVAC area.
Our products have been exported to Europe, USA, Japan and Middle east etc.
Condenser | FSKMQ 34 | FSKMQ 51 | FSKMQ 68 | FSKMQ 85 | FSKMQ 102 | FSKMQ 136 | FSKMQ 170 | FSKMQ 204 |
Air volume m3/h | H | 340 | 510 | 680 | 850 | 1020 | 1360 | 1700 | 2040 |
M | 270 | 410 | 550 | 680 | 820 | 1090 | 1360 | 1640 |
L | 200 | 310 | 410 | 510 | 620 | 820 | 1020 | 1230 |
Voltage | V | 220/110 |
Frequency | Hz | 50/60 |
Cooling (W) | At high air volume | 1800 | 2700 | 3600 | 4500 | 5400 | 7200 | 9000 | 10800 |
Heating (W) | 2700 | 4050 | 5400 | 6750 | 8100 | 10800 | 13500 | 16200 |
Input power (W) | 33 | 45 | 68 | 80 | 98 | 136 | 160 | 176 |
Noise dB(A) | 36 | 38 | 40 | 42 | 45 | 46 | 47 | 49 |
Flow 1/min | 5.2 | 7.8 | 10.4 | 12.9 | 15.5 | 20.7 | 25.8 | 31 |
Water resistance k pa | 4 | 6 | 8 | 12 | 17 | 13 | 20 | 24 |
Material & Part | Fan | Type | Centrifugal forward inclined impeller (galvanized sheet) |
Quantity | 1 | 2 | 2 | 2 | 2 | 4 | 4 | 4 |
Electric motor | Type | Permanent capacitor motor |
Quantity | 1 | 1 | 1 | 1 | 1 | 2 | 2 | 2 |
Coil | Type | Copper tube with aluminium fin |
Nozzle | Intake pipe | 3/4" Female thread (copper) |
Outlet pipe | 3/4" Male thread (copper) |
Net weight kg | FSKMQ | 37 | 40 | 52 | 52 | 66 | 69 | 69 | 74 |
1.material :copper , aluminum ,galvanized plate
2. aluminum foil: hydrophilic or bare
3. fin type: louver fin or flat fin or corrugated fin
4. copper pipe: diameter 7mm or 8mm or 9.52mm ,grooved or smooth tube
5. pitch of fins can be adjusted between 1.8—5.8mm.
6. pitch of holes and pitch of rows : 25*21.65MM and 12.7*19.05MM
7. suitable for R134A, R22, R404A, R407C refrigerant and so on
8. voltage: 220V/1/50HZ and 380V/3/50HZ or other type.
9. different alternative condensing fans available: shaded pole or outer rotor fan motor.
10.did gas examination under 3.0Mpa air pressure to ensure the tightness.
11.widely used in refrigeration industry, cold room and other cooling system.
12. we can supply products as per customized samples or drawing.
12.producing procedure: tube bending, punching fin, expanding, digressing, drying
Welding, leakage test, bending, inspection, packing
Note: for further information please contact us
